Sculpfun

Sculpfun 1064nm Infrared Laser Module IR-2 0.03mm Laser Spot For Metal And Plastic Engraving

Sculpfun 1064nm Infrared Laser Module IR-2 0.03mm Laser Spot For Metal And Plastic Engraving

Regular price €439,99 EUR
Regular price €459,99 EUR Sale price €439,99 EUR
Sale Sold out
Main feature:
1- Engravable Materials: 1064nm infrared laser module is suitable for engraving on a wide variety of metals including gold, silver, platinum, copper, aluminum, zinc, iron, stainless steel, metal oxides and alloys, plastics, and Dark acrylics.
2- High Precision: The laser module adopts ultra fine 0.03mm laser spot with high accuracy, which can engrave more delicate patterns on various metal materials.
3- 20000Hz Pulse Energy: The pulse energy of the Sculpfun laser module can reach up to 20000Hz. It can easily engrave on metals and show clear traces.
4- High Adaptability: Compatible with all Sculpfun laser engravers, including S6, S6 Pro, S9, S10, S30 Series, S30 Ultra Series and SF-A9. Equipped with 3 different types of mounting plates, it can meet the needs of different machine structures. And it can be quickly focused by pulling down the focus lever.

Note: In addition to these three structures, if your machine is any other structures, please contact us to confirm the compatibility.

Model: IR-2
Light Output Power: >2W
Product Material: aluminium alloy
Laser Wavelength: 1064nm
Working Mode: pulse operation
Spot Size: X:0.03mm Y:0.003mm
Power Supply: DC24V(80W)
Storage Temperature: -10°C-50°C

Product Size: 144*50*58mm
Product Weight: 0.45KG

Package Size: 295*231*80mm
Package Weight: 1.5KG

Packing List:
1 × 2W Infrared Laser Module
1 × Adapter
1 × S10 Mounting Plate
1 × SF-A9 Mounting Plate
1 × Universal Mounting Plate for Other Models
1 × Accessories Package
